Product application:

Teflon (PTFE) platinum silicone hose BT20 series are widely used in high and low temperature food dairy products and oils, cosmetics, chemical industry and pharmaceutical industry and biological engineering in liquid or semi-liquid products conveying fluid, (biological engineering equipment, laboratory equipment, medical equipment connecting line, etc.)

Product description:

The silicone hose used to strengthen 304 stainless steel wire braided PTFE and platinum silicone combination. Widely used in food, medicine and cosmetics, liquid and semi-liquid of biological engineering.

Standard length of 20 meters per volume, at the same time, we can produce according to customer requirements stipulated by the size and length of hose products by the FDA and USP Class VI and BFRS certification in Germany.

Product features:

Teflon (PTFE) platinum silicone hose BT20 series:

- working temperature range '- 60 DHS C/C + 120 DHS (76 + 248 DHS DHS F/F) in a short period of time can reach 150 DHS C (302 DHS F)

- has good acid and alkali resistance, has excellent chemical stability. Can resistance to high pressure, the lining has good abrasion resistance.

- has excellent flexibility, wall smooth, clean, easy to clean, non-stick water with clean after cleaning is not attached to any residue, high temperature and high pressure steam disinfection and sterilization can be used.

, odorless, tasteless, completely non-toxic, does not contain any plasticizer and additives. Completely conforms to the food and the requirements of the USP VI biomedical level.

- these are usually the outer tube for the milky white platinum vulcanization silicone. We also can be made according to customer's required color to the outer.

Quality certification:

Silicone hose, platinum 21 CFR 177.2600 by FDA (food and drug administration) food grade certification.

Silicone hose, platinum by German BFRS part XV standard authentication and LFBG certification.

Silicone hose, platinum level through the U.S. medical USP Class VI standard certification.

- platinum silicone tube in accordance with the eu directive 2008/95 / ECC restrictions on the use of certain hazardous substances (RoHS).

In line with the ISO10993 - platinum silicone hose, 3.1.9 NSF51 and European pharmacopoeia requirements.
